Rackmount Chillers
Semiconductor Cooling •Laser Cooling
The environmentally friendly Rackmount Chillers from BV Thermal Systems provide continuous cooling with a temperature range of +5° to 35°C.
Standard features include the highest quality refrigeration and plumbing components in the industry – stainless steel evaporator/heat exchanger, hot gas bypass and fluid bypass/pressure regulating valve.
Rack Mount Chiller Specifications
| MODEL | MC017-19 | MC025-19 | MC033-19 | MC050-19 |
|---|---|---|---|---|
| Cooling Capacity | 500 watts @20°C | 861 watts @20°C | 1119 watts @20°C | 1702 watts @20°C |
| Stability | ±0.1°C | ±0.1°C | ±0.1°C | ±0.1°C |
| Temperature Range | +5°C to +35°C | +5°C to +35°C | +5°C to +35°C | +5°C to +35°C |
| Pump | 2.2 GPM to 60 PSI | 2.2 GPM to 60 PSI | 2.2 GPM to 60 PSI | 2.2 GPM to 60 PSI |
| Reservoir Volume | 0.55 gal | 0.55 gal | 0.55 gal | 0.55 gal |
| Power Requirements | 120V, 6A | 120V, 8A | 120V, 8A | 120V, 8A |
| Dimensions in”(w x d x h) | 17 x 22 x 15.75 | 17 x 22 x 15.75 | 17 x 22 x 15.75 | 17 x 22 x 15.75 |
| Weight (lbs) | 60 | 68 | 68 | 79 |
•Full featured PID controller with Auto-tuning •Internal pressure/flow adjustment
•Seamless polyethylene tank with easy fill 3″ port •O-ring, hard brazed or welded connections
•Adjustable temperature high & low alarm •UL, CE & RoHS certifiable
