Portable Chillers

2800 – 177,000 BTUH •5°C to 27°C
Quiet • Precise • Customize to Your Specifications

The environmentally friendly Recirculating Portable Chillers from BV Thermal Systems provide continuous cooling with a temperature range of +5° to 35°C.  Whether you require a standard model, rack mount, low temperature or a totally custom unit, BV Thermal Systems has the ability to help you.  Our standard units feature a low profile design with high quality, non-marring locking casters. The Recirculating Portable Chillers are manufactured to be energy efficient and cost effective.  Expect your recirculating chillers to  provide exceptional performance with unmatched reliability for many years.  It is this combination that makes our customers return over and over again when needing temperature control equipment.

Features Include:

•Corrosion free wetted surfaces
•Refrigerant receiver with access valve
•DIN rail CE components for easy service and safety
•PLC Driven – no proprietary PC boards
•Level, flow & temperature remote signals
•Hard brazed joints

Rackmount Chillers

Designed to fit a stanrackmount-outlineddard 19″ rack and featuring an easy front fill reservoir, auto-tuning, PID temperature controller and a liquid filled pressure gauge.

Benchtop Chillers

Designed for use with rotary evaporators, vacuum systems, spectrometers, medical laboratories, lasers and university Custom Benchtop Chillerlaboratories along with other analytical instrumentation.  The simple set-up, day to day operation and low maintenance  ensure that our benchtop chillers are lab-efficient and user-friendly.

Low Temperature Chillers

Offer continuous cooling with a temperature range from -40° to +30°C and are optimized at your load point for maximum efficiency.
dard 19″ rack and featuring an easy front fill reservoir, auto-tuning, PID temperature controller and a liquid filled pressure gauge.

Mercury Chillers

Offer continuous cooling with a temperature range from +5 to +27°C. Featuring a low profile design with high quality casters.

.

Recirculating Portable Chillers – Specifications

MODEL MC025 MC033 MC050 MC075 MC100 MC150 MC200
Cooling Capacity 828 watts @ 20°C 1073 watts @ 20°C 1764 watts @ 20°C 2681 watts @ 20°C 3163 watts @ 20°C 4895 watts @ 20°C 7000 watts @ 20°C
Stability ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C
Temperature Range +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c
Pump 2.2 GPM to 99 PSI 2.2 GPM to 99 PSI 2.2 GPM to 99 PSI 2.2 GPM to 99 PSI 2.2 GPM to 99 PSI 4.0 GPM to 99 PSI 4.0 GPM to 99 PSI
Reservoir Volume 1.3 gal 1.3 gal 1.3 gal 1.3 gal 2 gal 2 gal 7 gal
Dimensions (w x d x h) in 14.5 x 22 x 29 14.5 x 22 x 29 14.5 x 22 x 29 14.5 x 22 x 29 36 x 27 x 29.75 36 x 27 x 29.75 38 x 32 x 39
Power Requirements 115V, 9A 115V, 12A 200-230V, 8A 200-230V, 10A 200-230V, 12A 200-230V, 20A 200-230V, 17A
Weight (lbs) 130 130 142 180 258 270 404

MODEL MC300 MC400 MC500 MC600 MC800 MC1000 MC1500
Cooling Capacity 10,000 watts @ 20°C 12,800 watts @ 20°C 16,400 watts @ 20°C 20,000 watts @ 20°C 26,000 watts @ 20°C 34,500 watts @ 20°C 52,000 watts @ 20°C
Stability ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C ±0.1°C
Temperature Range +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c +5°c to +35°c
Pump 4.0 GPM to 99 PSI 10 GPM to 40 PSI 10 GPM to 40 PSI 10 GPM to 40 PSI 10 GPM to 40 PSI 10 GPM to 40 PSI 20 GPM to 40 PSI
Reservoir Volume 7 gal 7 gal 7 gal 7 gal 7 gal 7 gal 7 gal
Dimensions (w x d x h) in 38.5 x 32 x 39 48.5 x 33 x 48 48.5 x 33 x 48 65 x 45 x 42.25 65 x 45 x 42.25 65 x 45 x 42.25 65 x 45 x 42.25
Power Requirements 200-230V, 20A 200-230V-3, 16A 200-230V-3, 20A 200-230V-3, 22A 200-230V-3, 26A 460V-3, 20A 460V-3, 28A
Weight (lbs) 442 484 531 720 825 955 1100
